CytoFAST Elite 209
Technical sheet
Useful dimension (mm)::WxDxH: 887x580x740
Overall dimension [mm]: WxDxH: 1045x855x2345(*)
Noise level (dbA):Working Aperture (mm): 200
Exhaust flow rate (m3/h): 290
Lighting level (lux): >1100
Weight (kg): 215
Electrical data [230V – 50H] (**): 230 V – 50 Hz
Current consumption (A): 2,3
Heat emission (W): 175
(*) overall depth can be reduced to
(**) different voltage/frequency available upon request:
Accessories
FX0002124600 – UV Lamp for 0.9/1.2 mt size
FX0021449900 – Additional electrical socket
FX0002124710 – Additional Vacuum Tap
FX0021247200 – Additional Compressed Air Tap
FX0021247300 – Additional Nitrogen Tap
FX0021247400 – Additional Water Tap
FX0002124930 – Additional socket for data (RS232)
FX0002124920 – Additional socket for data (RS485)
FX0002124950 – Additional socket for data (RJ45)
FX0021450200 – Additional socket for data (USB)
FX0021144300 – Filter cover to enable the installation of perforated work surface in CF Elite 209
FX0021141100 – Replacement of HEPA filters under the work surface with activated charcoal filters in CF Elite 209, factory fitted
FX0002094030 – Exhaust charcoal filter without collar for 0.9 mt size
FX0002094020 – Additional exhaust HEPA filter without collar for 0.9 mt size
FX0002124940 – Volt free contact
FX0002124800 – Anti-blowback valve
A00XBBB54 – Touch screen controls
FX0002094040 – Exhaust hard duct connection 0.9 mt size
FX0002094070 – Exhaust thimble connection 0.9 mt size
FX0002124200 – Arm rests (couple)
FX0002094220 – Stainless steel bar for bags with 6 hooks for CytoFAST Elite 209
FX0021143400 – Kit to modify the CF Elite 209 as powder weighing station with solid work surface
A00XBBB51 – Adjustable electrical stand (stroke 700-1000mm) for 0.9 mt size
